Frame
FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-2™ Adjustable Geometry | 130mm Travel | FORM™ Alloy Rear Triangle
Fork
Manitou JUNIT 34 Expert 140mm | 26" = 41mm Offset
Front Travel
140
Shock
RockShox Deluxe Select | Sealed Bearing Eyelet | 20x8mm F Hardware | 190x40mm
Rear Travel
130
Headset
FSA ZS56|66 Reach Adjust | 5mm Cups Installed | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
Handlebar
Rocky Mountain Jr | 640mm Width |25mm rise | 9° Backsweep |5° Upsweep | 31.8 | For 19mm Grips
Grips
SGD Slater JR Lock On
Brakes
Tektro HD-J2820 | Short Reach Lever | Shimano Pad Compatible
Rotors
Tektro 180mm | Tektro 180mm
Shifters
MicroShift Advent X 10spd
Rear Derailleur
MicroShift Advent X 10spd With Clutch
Crankset
Rocky Mountain Microdrive 2PC | 30T | 104mm BCD | 24mm Spindle | Crank Length = 155mm
Cassette
Sunrace CSMS2 11-46T
Chain
KMC X10-1
Front Hub
Shimano TC500 Boost 15x110m | 28H
Rear Hub
Shimano TC500 Boost 148mm | 28H
Spokes
2.0 Stainless
Rims
WTB KOM Team i30 TCS 2.0 | 28H
Tires
F: Maxxis Minion DHF 2.5 WT EXO Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready
Seatpost
Tranz X +RAD1.0 Adjustable Dropper Post | 30mm Adjustment | Alloy Clamp Lever | 30.9mm | 125mm
Saddle
Rocky Mountain Kids
