Frame
SMOOTHWALL™ Carbon | SMOOTHLINK SL™ Suspension | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | RIDE-4™ Adjustable Geometry | 120mm Travel | SMOOTHWALL™ Carbon Rear Triangle
Fork
Fox 34 SL Factory 29 130mm | GRIP X Damper | 44mm Offset
Front Travel
130
Shock
Fox Float Factory | Sealed Bearing Eyelet | 20x8mm F Hardware | All Sizes = 190x45mm | Size-Specific tune in FAQ
Rear Travel
120
Headset
FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 35 XC | 0° Rise | All Sizes = 50mm
Handlebar
Race Face Turbine | XS = 760mm | SM - XL = 780mm Width | 20mm Rise | 8° Backsweep | 5° Upsweep | 35mm Clamp
Grips
ODI Elite Pro Lock On
Brakes
Shimano XT Trail 4 Piston | Metal Pads
Shifters
Shimano XT Di2 Wireless
Rear Derailleur
Shimano XT Di2 Wireless
Cranks & Chainring
Shimano XT | 32T | 24mm Spindle | 176mm Q-Factor | Crankarm Length: XS - SM = 165mm | MD - XL = 170mm
Bottom Bracket
Shimano SM-BBMT500
Cassette
Shimano XT 10-51T
Chain
Shimano M8100
F / Wheel
DT Swiss M1900
R / Wheel
DT Swiss M1900 | 370 SPLINE Boost 148mm | 18T Ratchet LN
Tires
F: Maxxis Rekon WT 3C MaxxTerra EXO Tubeless Ready 2.4 | R: Maxxis Rekon WT 3C MaxxTerra EXO Tubeless Ready 2.4
Seatpost
Tranz X +RAD2.0 Adjustable Dropper Post | 30mm Adjustment | Alloy I-Spec EV Lever | 30.9mm | XS = 120mm | SM = 150mm | MD = 170mm | LG = 200mm | XL = 230mm
Saddle
WTB Solano Fusion Form 142 | Cromoly Rails
