Frame
SMOOTHWALL™ Carbon | SMOOTHLINK SL™ Suspension | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | RIDE-4™ Adjustable Geometry | 120mm Travel | SMOOTHWALL™ Carbon Rear Triangle
Fork
RockShox Pike Select 130mm | Charger RC Damper | 27.5 = 37mm Offset | 29 = 42mm Offset
Front Travel
130
Shock
RockShox Deluxe Select+ | Sealed Bearing Eyelet | 20x8mm F Hardware | All Sizes = 190x45mm |Size-Specific tune in FAQ
Rear Travel
120
Headset
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 35 XC | 0° Rise | All Sizes = 50mm
Handlebar
Rocky Mountain AM | XS = 760mm | SM - XL = 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Grips
ODI Elite Pro Lock On
Brakes
Sram Motive Bronze 4 Piston | Metal Pads
Shifters
Sram Eagle 90 Transmission
Rear Derailleur
Sram Eagle 90 Transmission
Cranks & Chainring
Sram Eagle 70 | 32T | DUB Spindle | Crankarm Length: SM = 165mm | MD - XL = 170mm
Bottom Bracket
Sram BB92 DUB Wide
Cassette
Sram XS-1270 Eagle Transmission 10-52T
Chain
Sram Eagle 70 Transmission
Front Hub
Novatec D791SB Sealed Boost 15mm
Rear Hub
DT Swiss 370 Boost 148mm | 18T Ratchet LN
Spokes
DT Swiss Competition 2.0/1.8/2.0
Rims
WTB KOM Team i27 TCS 2.0 | 28H
Tires
F: Maxxis Rekon WT 3C MaxxTerra EXO Tubeless Ready 2.4 | R: Maxxis Rekon WT 3C MaxxTerra EXO Tubeless Ready 2.4
Seatpost
Tranz X +RAD2.0 Adjustable Dropper Post | 30mm Adjustment | Alloy MMX Lever | 30.9mm | XS = 120mm | SM = 150mm | MD = 170mm | LG = 200mm | XL = 230mm
Saddle
WTB Silverado Race 142 | Cromoly Rails
