Frame
SMOOTHWALL™ Carbon | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-4™ Adjustable Geometry | 145mm Travel | SMOOTHWALL™ Carbon Rear Triangle
Fork
RockShox Lyrik Select 160mm | Delta RC Damper | 27.5 = 37mm Offset | 29 = 42mm Offset
Front Travel
160
Shock
SM-XL: Rock Shox Super Deluxe Select+ | Linear XL Air Can | 230x60mm | XS: Rock Shox Deluxe Ultimate | Linear XL Air Can | 210x55mm | Sealed Bearing Eyelet | 25x8mm F Hardware | Size-Specific tune in FAQ
Rear Travel
150
Headset
FSA Orbit NO.85 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Grips
ODI Elite Pro Lock On
Brakes
Shimano XT Trail 4 Piston | Metal Pads
Shifters
Shimano XT
Rear Derailleur
Shimano XT
Cranks & Chainring
Race Face Turbine Cinch | 34T Ring | 30mm Spindle | XS - XL = 165mm
Bottom Bracket
Race Face BB92 30mm
Cassette
Shimano Deore 10-51T 12spd
Chain
Shimano M6100
Front Hub
Novatec D791SB Sealed Boost 15mm
Rear Hub
Novatec MTB SL Pro Boost 148mm
Spokes
DT Swiss Competition 2.0/1.8/2.0
Rims
WTB KOM Trail i30 TCS 2.0 | 28H
Tires
F: Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready
Seatpost
Tranz X +RAD2.0 Adjustable Dropper Post | 30mm Adjustment | Alloy I-Spec EV Lever | 30.9mm | XS = 120mm | SM = 150mm | MD = 170mm | LG = 200mm | XL = 230mm
Saddle
WTB Volt Fusion Form 142 | Cromoly Rails
Drive System
Dyname S4 Lite Mountain Bike Drive | 250w Nominal Power | 700w Max Power | 75Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada
Battery
480 Wh Removable Integrated Li-Ion
Display
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration
Charger
Rocky Mountain Powerplay FAST Charger | 4A | 48V | Higo Deep Socket Connector
Weight
44 LBS | 20 kg
