Frame
FORM™ Alloy | Full Sealed Cartridge Bearings | Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel | FORM™ Alloy Rear Triangle
Fork
Fox 38 Float EVOL GRIP X2 Factory Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
Front Travel
170
Shock
Fox DHX2 Coil Factory | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Coil Spring SM - MD - LG - XL = 400 - 450 - 500 - 550
Rear Travel
160
Headset
FSA ZS56/66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm
Handlebar
Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Grips
ODI Elite Pro Lock On
Brakes
TRP DH-R EVO PRO | Metallic Pads
Shifters
Sram Eagle 90 Transmission
Rear Derailleur
Sram Eagle 90 Transmission
Cranks & Chainring
Sram Eagle 90 | 32T | DUB Spindle | Crankarm Length: SM MD = 165mm | LG - XL = 170mm
Bottom Bracket
Sram DUB BSA 73 Wide
Cassette
Sram XS-1270 Eagle Transmission 10-52T
Chain
Sram Eagle 70 Transmission
F / Wheel
DT Swiss E1900
R / Wheel
DT Swiss E1900 | 370 SPLINE Boost 148mm | 18T Ratchet LN
Tires
F: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready
Seatpost
Tranz X +RAD2.0 Adjustable Dropper Post | 30mm Adjustment | Alloy MMX Lever | 30.9mm | SM = 150mm | MD = 170mm | LG = 200mm | XL = 230mm
Saddle
WTB Solano Fusion Form 142 | Cromoly Rails
