Frame
FORM™ Alloy | Full Sealed Cartridge Bearings | Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel | FORM™ Alloy Rear Triangle
Fork
RockShox Zeb RC 170mm | 27.5 = 38mm Offset | 29 = 44mm Offset
Front Travel
170
Shock
RockShox Super Deluxe Select+ | Linear XL Air Can | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ
Rear Travel
160
Headset
FSA ZS56/66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race
Stem
Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm
Handlebar
Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Grips
ODI Elite Pro Lock On
Brakes
Sram Maven Stealth 4 Piston | Metal Pads
Shifters
Sram Eagle 90 Transmission
Rear Derailleur
Sram Eagle 70 Transmission
Cranks & Chainring
Sram Eagle 70 | 32T | DUB Spindle | Crankarm Length: SM MD = 165mm | LG - XL = 170mm
Bottom Bracket
Sram DUB BSA 73 Wide
Cassette
Sram XS-1270 Eagle Transmission 10-52T
Chain
Sram Eagle 70 Transmission
Front Hub
Novatec D791SB Sealed Boost 15mm
Rear Hub
Novatec MTB SL Pro Boost 148mm
Spokes
2.0 Stainless
Rims
WTB ST i30 TOUGH TCS 2.0 | 32H
Tires
F: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready
Seatpost
Tranz X +RAD2.0 Adjustable Dropper Post | 30mm Adjustment | Alloy MMX Lever | 30.9mm | SM = 150mm | MD = 170mm | LG = 200mm | XL = 230mm
Saddle
WTB Solano Fusion Form 142 | Cromoly Rails
