Rám
FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | 120mm Travel | FORM™ Alloy Rear Triangle
Vidlice
Manitou J Unit Comp 120mm | TPC Damper | 20 = 40mm Offset
Zdvih vidlice
120
Tlumič
RockShox Deluxe Select | Sealed Bearing Eyelet | 20x8mm F Hardware | 170x35mm
Zdvih tlumiče
120
Hlavové složení
FSA Orbit NO.57B ZS44|56 | Retainer Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Představec
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
Řidítka
Rocky Mountain Jr | 600mm Width | 25mm rise | 9° Backsweep | 5° Upsweep | 31.8 | For 19mm Grips
Gripy
SGD Slater JR Lock On
Brzdy
Tektro HD-J2820 | Short Reach Lever | Shimano Pad Compatible
Kotouče
Tektro 160mm | Tektro 160mm
Řazení
MicroShift Advent Short Reach 9spd
Přehazovačka
MicroShift Advent Super Short 9spd W/Clutch
Kliky
Rocky Mountain Microdrive 2PC | 28T | 104mm BCD | 24mm Spindle | Crank Length = 127mm
Kazeta
SunRace CSM98 11-36T
Řetěz
KMC X9
Přední náboj
Shimano TC500 Boost 15x110m | 28H
Zadní náboj
Shimano TC500 Boost 148mm | 28H
Špice
2.0 Stainless
Ráfky
WTB ST Light i27 TCS 2.0 Tubeless Compatible | 28H
Pláště
Kenda Regolith 20 x 2.4 | Kenda Regolith 20 x 2.4
Sedlovka
X Fusion Manic Composite 30.9mm | 80mm
Sedlo
Rocky Mountain Kids
